STANDARD LIDAR BROWSE IMAGES FOR PRODUCTION RELEASE [V5.00] BROWSE DATE [2008-09-10]

Displayed on this page are scaled, color-modulated, altitude-time images of CALIPSO attenuated backscatter (/km/sr) including:

• 532 nm total (parallel + perpendicular) attenuated backscatter
• 532 nm perpendicular attenuated backscatter
• 1064 nm total attenuated backscatter

The orbit track locations for the entire Level 1 .hdf file are in black and the orbit track locations corresponding to this page are color coded.

For the full scale images:

• the color bars for attenuated backscatter show the colors assigned to ranges of attenuated backscatter, /km/sr
• the horizontal axes are annotated with latitude (deg) and longitude (deg)
• the vertical axes are annotated to indicate altitude in kilometers
• the date and time of the measurements are listed as UTC time
• the names of the CALIPSO data products for the Lidar Level 1 attenuated backscatter granules are included

The scaled images on this page are organized by CALIPSO data product day and night orbit granules.

The maps with a shaded background indicate nightime measurements.

There are a maximum of 4 scaled images per granule.

The orbit tracks plotted on the maps show the measurement locations for each granule.

For each granule, the scaled images are ordered from left to right and their locations along the orbit tracks are color coded as: image one, image two, image three, image four.

Begin	End	Number Profiles
2008/09/10 15:07:45.5360 UTC	2008/09/10 16:00:14.5234 UTC	63495

Begin	End	Number Profiles
2008/09/10 16:46:37.5990 UTC	2008/09/10 17:39:07.3694 UTC	63510

Begin	End	Number Profiles
2008/09/10 18:25:30.4450 UTC	2008/09/10 19:17:59.4874 UTC	63495

Begin	End	Number Profiles
2008/09/10 20:04:23.3169 UTC	2008/09/10 20:56:52.3654 UTC	63495

Begin	End	Number Profiles
2008/09/10 21:43:15.4640 UTC	2008/09/10 22:35:45.2624 UTC	63510

Begin	End	Number Profiles
2008/09/10 23:22:08.3700 UTC	2008/09/11 00:14:37.4294 UTC	63495
