STANDARD LIDAR BROWSE IMAGES FOR PRODUCTION RELEASE [V5.00] BROWSE DATE [2015-06-29]

Displayed on this page are scaled, color-modulated, altitude-time images of CALIPSO attenuated backscatter (/km/sr) including:

• 532 nm total (parallel + perpendicular) attenuated backscatter
• 532 nm perpendicular attenuated backscatter
• 1064 nm total attenuated backscatter

The orbit track locations for the entire Level 1 .hdf file are in black and the orbit track locations corresponding to this page are color coded.

For the full scale images:

• the color bars for attenuated backscatter show the colors assigned to ranges of attenuated backscatter, /km/sr
• the horizontal axes are annotated with latitude (deg) and longitude (deg)
• the vertical axes are annotated to indicate altitude in kilometers
• the date and time of the measurements are listed as UTC time
• the names of the CALIPSO data products for the Lidar Level 1 attenuated backscatter granules are included

The scaled images on this page are organized by CALIPSO data product day and night orbit granules.

The maps with a shaded background indicate nightime measurements.

There are a maximum of 4 scaled images per granule.

The orbit tracks plotted on the maps show the measurement locations for each granule.

For each granule, the scaled images are ordered from left to right and their locations along the orbit tracks are color coded as: image one, image two, image three, image four.

Begin	End	Number Profiles
2015/06/29 19:53:15.5450 UTC	2015/06/29 20:39:48.2063 UTC	56310

Begin	End	Number Profiles
2015/06/29 20:39:48.2559 UTC	2015/06/29 21:32:08.3804 UTC	63315

Begin	End	Number Profiles
2015/06/29 21:32:08.4300 UTC	2015/06/29 22:18:41.1043 UTC	56310

Begin	End	Number Profiles
2015/06/29 22:18:41.1539 UTC	2015/06/29 23:11:00.5413 UTC	63300

Begin	End	Number Profiles
2015/06/29 23:11:00.5909 UTC	2015/06/29 23:57:34.0213 UTC	56325

Begin	End	Number Profiles
2015/06/29 23:57:34.0710 UTC	2015/06/30 00:49:53.4623 UTC	63300
