DATA AVAILABILITY
86.3% Click for more details

Displayed on this page are scaled, color-modulated, altitude-time images of CALIPSO attenuated backscatter (/km/sr) including:

532 nm total (parallel + perpendicular) attenuated backscatter
532 nm perpendicular attenuated backscatter
1064 nm total attenuated backscatter

The orbit track locations for the entire Level 1 .hdf file are in black and the orbit track locations corresponding to this page are color coded.

For the full scale images:

the color bars for attenuated backscatter show the colors assigned to ranges of attenuated backscatter, /km/sr
the horizontal axes are annotated with latitude (deg) and longitude (deg)
the vertical axes are annotated to indicate altitude in kilometers
the date and time of the measurements are listed as UTC time
the names of the CALIPSO data products for the Lidar Level 1 attenuated backscatter granules are included

The scaled images on this page are organized by CALIPSO data product day and night orbit granules.

The maps with a shaded background indicate nightime measurements.

There are a maximum of 4 scaled images per granule.

The orbit tracks plotted on the maps show the measurement locations for each granule.

For each granule, the scaled images are ordered from left to right and their locations along the orbit tracks are color coded as: image one, image two, image three, image four.
